Maintenance Manual (960-942) 4-25
Replacement Procedures
Figure 4-29 Installing the Wireless LAN card (1)
6. Stick a new INSU WL in place.
Figure 4-30 Installing the Wireless LAN card (2)
Camera
harness
Wireless LAN
antenna cables
INSU WL
