Maintenance Manual (960-942) 4-44
Replacement Procedures
Figure 4-53 Removing the display hinges
4.25.2 Installing the display hinges
To install the display hinges, follow the steps below and refer to Figure 4-
53.
1. Set the left & right hinges and secure them with the screws.
1
2
2
1
2
2
