dynabook PORTEGE X40-J Series - Table C-10 CN9540 Web Camera Interface Connector; Table C-11 CN5390 LCD Interface Connector

Maintenance Manual (960-942) C-11
Pin Assignments
C.1.10 CN9540 Web camera interface connector
Table C-10 CN9540 Web camera interface connector
C.1.11 CN5390 LCD interface connector
Table C-11 CN5390 LCD interface connector
Pin No. Signal Name Pin No. Signal Name
12
11
10
9
8
7
1T
GND
SIG9711
SIG9710
GND
GND
GND
GND
6
5
4
3
2
1
2T
CAMDET-P3N
XDMCL2-P3P
CRFRST-E1N
P3V
P3V
P3V
GND
