Maintenance - 1000h
ICA134-3EN2.pdf2012-04-13
Fig. Planetary gear/filling position
1. Plug
1
Position the roller with the plug (1) in the planetary
gear in the "9 o'clock" position.
Fill with oil to lower edge of level hole. Use
transmission oil. See the lubrication specification.
Clean and refit the plug.
Check the fluid level in the same way on the rear
axle's other planetary gear.
93
