Menu structure of CI 3000
87
Version 2.09 09. April 2014
Warning - hazardous electrical voltage!
Danger of destruction of components! When the meter signal is connected to the SIOX input via
a S0 port of the meter, the jumper of the input must be set to 24 V AC. (See Section 5.5.3 SIOX -
Energy, gas and water meters).
Allowance must be made for the meter and transformer constant settings when using electronic me
ters, as otherwise energy evaluation by the CI 3000 Store Computer will be inaccurate due to faulty
meter and transformer ratios!
S Maske 6-1-6-1-2 Search M-bus
Info screen for displaying existing M-bus nodes. The nodes must be connected to the M-bus and the COM2
interface of the M-bus must be activated. The configuration of the M bus interface is conducted via menu 6-1-9.
Following the selection of this screen an automatic search run is conducted. The screen can only be
exited once the cycle (up to a total of 250 nodes) has been completed and the ESC button subse
quently pressed.
M-bus
Search : xxx Once the search for 250 nodes has been completed, the screen displays ”finished”.
This can then be exited via ESC.
Found: xxx Number of M-bus nodes found
If no M-bus is configured, then the following screen appears.
NO
M bus
configured !
Please press ESC
Exit screen via ESC!
