The two channels in the system should have the channel information settings
matching those in table 5 below.
Table 5 Initial database channel settings
TP Temperature Channel
9830 CO Channel
System Channel #
1
2
Label
Temp
CO
Analogue Input #
16
N/A
Multiplier
100
1
Offset
-273
0
Units
°C
ppm
Decimal Places
1
2
High Alarm
40
4
Low Alarm
0
0
Alarm Number
1
2
Valid Data High
0
0
Valid Data Low
0
0
Channel Type
Voltage
Voltage
Process
Average
Average
Description
Ambient Temperature
Carbon Monoxide
Log Report 1
Set (ticked)
Set (ticked)
Log Report 2
Set (ticked)
Set (ticked)
Log Report 3
Set (ticked)
Set (ticked)
Log Report 4
Set (ticked)
Set (ticked)
Out of Service
Unset (not ticked)
Unset (not ticked)
Serial Port Output
Set (ticked)
Set (ticked)
Alternate File Output
Set (ticked)
Set (ticked)
Select the Calibration control tab and an almost empty table will appear. While there
is nothing in there yet, this option allows you to set which digital channels go
high(H)/low(L)/no change when the analogue channels on the analyser go into
calibration.
