Termination Panel by default and have all of its parameters set to default values.
Change the Model of the analyser to be 9841. The picture in the top right hand corner
should change to show an Ecotech analyser. Enter settings for the analyser as shown
in table 8.
Table 8 Settings for the Ecotech 9841 Nitrous Oxide analyser.
Ecotech EC9841
INFORMATION
Label
9841
Manufacturer
Ecotech
Model
9841
Device ID
41
Data Request Period
10
Max Response Time
1
Request Delay
0
COMMUNICATION SETTINGS
Connection Type
Serial RS232
Serial Port
3
Baud Rate
9600
Data Bits
8
Parity
None
Stop Bits
1
Note: Remember to set the baud rate on
the Ecotech EC9800 analyser to 9600 and
the Main Gas ID to 041 to match the
settings in WinAQMS Mini DAS.
