Patient Monitor User Manual Specifications
- 165 -
Appendix I Specifications
A1.1 Classification
Anti-electroshock Type
Class I equipment and internal powered equipment
Anti-electroshock Degree
ECG (RESP), TEMP, IBP CF
SpO
2
, NIBP, CO
2
BF
Ingress Protection
IPX1
Degree of Safety in Presence of
Flammable Gases
Not suitable for use in presence of flammable gases
Disinfection/Sterilizing method
Refer to Chapter 12 for details.
Working System
Continuous operation equipment
Compliant with Safety Standards
IEC 60601-1: 2005+A1: 2012; EN 60601-1: 2006+A1:
2013; IEC 60601-1-2: 2014; EN 60601-1-2: 2015;
IEC60601-2-49: 2011
A1.2 Specifications
NOTE:
The performance of the equipment with mark is determined to be essential
performance.
A1.2.1 Physical Specifications
Product
Size (W×D)
Shell figure / Screen
size
Weight
Remark
iM8
319 mm×267.8 mm×154 mm
Square /12.1-inch
<5kg
not including
the battery and
recorder
iM8A
319 mm×267.8 mm×154 mm
Square /10.4-inch
<5kg
iM8B
319 mm×267.8 mm×154 mm
Square /10.1-inch
Wide-screen
<5kg
M8
320 mm×265 mm×150 mm
Square /12.1-inch
<5kg
