Patient Monitor User Manual Specifications
- 182 -
NOTE:
Respiration Rate accuracy was verified by using a solenoid test setup to deliver a square
wave of known CO
2
concentration to the device. 5% and 10% CO
2
concentrations were
used. Respiration rate was varied over the range of the device. Pass/Fail criteria was
comparison of the respiratory rate output from the sensor to the frequency of the square
wave.
A1.2.16 Interfaces
USB Interface
Number of USB Interfaces
Standard: 1
Drive Mode
HOST interface, USB1.0/2.0 protocol
Power Supply
5 VDC±5%, 500 mA Max.
Interface Type
USB A-type port
VGA Interface
Number of VGA Interface
1
Horizontal Refreshing Rate
30 KHZ - 94 KHZ
Video Signal
0.7 Vpp @ 75 Ohm, HSYNC/VSYNC signal TTL
Interface Type
DB-15 female receptacle
Network Interface
Bandwidth
10 M/100 M
Interface Type
Standard RJ-45 network interface; PIN7 and PIN8 are
used for nurse call.
