Patient Monitor User Manual Specifications
- 172 -
Response time of Heart Rate
Meter to Change in HR
HR range: 80 bpm to 120 bpm
Range : Within 11 s
HR range: 80 bpm to 40 bpm
Range : Within 11 s
Tall T-wave Rejection
Complies with IEC 60601-2-27: 2011, Sect.
201.12.1.101.17 minimum recommended 1.2 mV T-Wave
amplitude
Accuracy of Heart Rate Meter
and Response to Irregular
Rhythm
Complies with IEC 60601-2-27: 2011, Sect.
201.7.9.2.9.101 b) 4) the HR value after 20 seconds of
stabilization is displayed as follows:
Ventricular bigeminy: 80 bpm±1 bpm
Slow alternating ventricular bigeminy: 60 bpm±1 bpm
Rapid alternating ventricular bigeminy: 120 bpm±1 bpm
Bidirectional systoles: 91 bpm±1 bpm
Arhythmia analysis
ASYSTOLE
VFIB/VTAC
COUPLET
VT>2
BIGEMINY
TRIGEMINY
VENT
R on T
PVC
TACHY
BRADY
MISSED BEATS
IRR
VBRADY
PNC
PNP
A1.2.9 RESP
Method
Trans-thoracic impedance: R-F(RA-LL), R-L (RA-LA)
RR measuring range
Adult:
0 rpm to 120 rpm
Neo/Ped
0 rpm to 150 rpm
Resolution
1 rpm
Accuracy
Adult
6 rpm to 120 rpm: 2 rpm
0 rpm to 5 rpm: Undefined
