EDAN M8 Series - 7.4 Adjustable Range of Alarm Limits

Patient Monitor User Manual Alarm Information
- 67 -
SpO
2
SEARCH
PULSE
SpO
2
module is analyzing the patient signal and
searching for the pulse to compute the saturation,
when sensor is connected with patient.
ARR LEARNING
The QRS template building required for Arr.
Analysis is in process.
CH1 ZERO FAIL!
IBP channel 1 sensor off during zeroing, or channel
1 pressure exceeds the zero range.
CH1 ZERO
SUCCESS!
IBP channel 1 zero ok.
CH2 ZERO FAIL!
IBP channel 2 sensor off during zeroing, or channel
2 pressure exceeds the zero range.
CH2 ZERO
SUCCESS!
IBP channel 2 zero ok.
CH1 CAL FAIL!
IBP channel 1 sensor off during calibration.
CH1 CAL SUCCESS!
IBP channel 1 calibration ok.
CH2 CAL FAIL!
IBP channel 2 sensor off during calibration.
CH2 CAL SUCCESS!
IBP channel 2 calibration ok.
CO
2
Zero Start
CO
2
module starts zero calibration.
CO
2
Zero OK
CO
2
module completes zero calibration.
7.4 Adjustable Range of Alarm Limits
ECG adjustable range of alarm limits are listed as follows (unit bpm):
Patient Type
ALM HI
ALM LO
HR
ADU
300
15
PED
350
15
NEO
350
15
ST analysis adjustable range of alarm limits are listed as follows (unit mV):
ALM HI
ALM LO
ST
2.0
-2.0
PVCs alarm upper limits are listed as follows:
ALM HI
PVCs
10
