EDAN M8 Series User Manual

Patient Monitor User Manual Specifications
- 169 -
A1.2.8 ECG
Complies with IEC 60601-2-27: 2011.
Lead Mode
3-Lead: I, II, III
5-Lead: I, II, III, aVR, aVL, aVF, V
Lead naming style
AHA, IEC
☆ Display Sensitivity (Gain
Selection)
1.25 mm/mV (×0.125), 2.5 mm/mV (×0.25), 5 mm/mV
(×0.5), 10 mm/mV (×1), 20 mm/mV (×2), 40 mm/mV
(×4), AUTO gain
☆Sweep speed
6.25 mm/s, 12.5 mm/s, 25 mm/s, 50 mm/s
Bandwidth (-3dB)
Diagnosis: 0.05 Hz to 150 Hz
Monitor: 0.5 Hz to 40 Hz
Surgery: 1 Hz to 20 Hz
☆ CMRR (Common Mode
Rejection Ratio)
Diagnosis: >95 dB
Monitor: >105 dB
Surgery: >105 dB
Notch
50 Hz/60 Hz (Notch filter can be turned on or off
manually)
☆Differential Input Impedance
>5 MΩ
☆Input Signal Range
±10 mV PP
☆ Accuracy of Input Signal
Reproduction
The total error and frequency response comply with IEC
60601-2-27:2011 Sec. 201.12.1.101.1.
☆ Electrode Offset Potential
Tolerance
±500 mV
Auxiliary Current (Leads off
detection)
Active electrode: <100 nA
Reference electrode: <900 nA
☆ Recovery time after
Defibrillation
<5 s (measured without electrodes as
IEC60601-2-27:2011, Sect. 201.8.5.5.1 requires.)
Sampling Frequency
1000 Hz
Sampling Channel Switch Time
< 80 μS
A/D Precision
24 Bits
Leakage current of patient
<10 μA
Scale signal
1 mVPP, accuracy is ±5％
