EDAN M8 Series User Manual

Patient Monitor User Manual Specifications
- 170 -
☆System noise
<30 μVPP
☆ESU Protection
Cut mode: 300 W
Coagulation mode: 100 W
Restore time: ≤10 s
Electrosurgical Interference
Suppression
Test according to ANSI/AAMI EC13:2002, Sect. 5.2.9.14.
Complied with ANSI/AAMI EC13:2002, Sect. 4.2.9.14.
Pace Pulse
☆Pulse indicator
Pulse is marked if the requirements of IEC 60601-2-27:
2011, Sect. 201.12.1.101.12 are met:
Amplitude: ±2 mV to ±700 mV
Width: 0.1 ms to2.0 ms
Ascending time: 10 μs to 100 μs
☆Pulse Rejection
Pulse is rejected if the requirements of IEC 60601-2-27:
2011, Sect. 201.12.1.101.13 are met:
Amplitude: ±2 mV to ±700 mV
Width: 0.1 ms to 2 ms
Ascending time: 10 μs to 100 μs
Minimum input slew rate
(Lead II)
>2.5 V/S
☆Baseline reset
<3 s
Pace Pulse Detecting Lead
one among I, II, III, AVR, AVL, AVF, V1, V2, V3,V4,
V5, V6
Heart rate
☆Range
ADU: 15 bpm to 300 bpm
PED/NEO: 15 bpm to 350 bpm
☆Accuracy
±1% or 1 bpm, whichever is greater
Resolution
1 bpm
Sensibility
≥300 μVPP
PVC
Range
ADU: 0 PVCs/ min to 300 PVCs/ min
PED/NEO: 0 PVCs/ min to 350 PVCs/ min
Resolution
1 PVCs/min
ST value
Range
-2.0 mV to +2.0 mV
