EDAN M8 Series User Manual

Patient Monitor User Manual Specifications
- 171 -
Accuracy
±0.02 mV or 10% (-0.8 mV to +0.8 mV), whichever is
greater. Beyond this range: not specified.
Resolution
0.01 mV
HR averaging method
Method 1
Heart rate is computed by excluding the minimum and
maximum values from the 12 most recent RR intervals and
averaging the residual 10 RR intervals.
Method 2
If each of three consecutive RR intervals is greater than
1200ms, then the four most recent RR intervals are
averaged to compute the HR.
Range of Sinus and SV Rhythm
Tachy
Adult: RR interval for 5 consecutive QRS complex ≤ 0.5 s.
Pediatric/neonatal: RR interval for 5 consecutive QRS
complex ≤ 0.375 s.
Normal
Adult: 0.5s < RR interval for 5 consecutive QRS complex
< 1.5 s.
Pediatric/neonatal: 0.375s < RR interval for 5 consecutive
QRS complex < 1 s.
Brady
Adult: RR interval for 5 consecutive QRS complex ≥ 1.5 s.
Pediatric/neonatal: RR interval for 5 consecutive QRS
complex ≥ 1 s.
Range of Ventricular Rhythm
Ventricular Tachycardia
The interval of 5 consecutive ventricular wave is less than
600 ms
Ventricular Rhythm
The interval of 5 consecutive ventricular wave ranges from
600 ms to 1000 ms
Ventricular Bradycardia
The interval of 5 consecutive ventricular wave is more than
1000 ms
Maximum Start-up Alarm Time for Tachycardia
Ventricular Tachycardia
1 mV 206bpm
Gain 0.5: 10 s
Gain 1.0: 10 s
Gain 2.0: 10 s
Ventricular Tachycardia
2 mV 195bpm
Gain 0.5: 10 s
Gain 1.0: 10 s
Gain 2.0: 10 s
