EDAN M8 Series User Manual

Patient Monitor User Manual EMC Information
- 184 -
Immunity test
IEC/EN 60601 test level
Compliance level
Electromagnetic
environment - guidance
Electrostatic
discharge (ESD)
IEC/EN 61000-4-2
8 kV contact
15 kV air
8 kV contact
15 kV air
Floors should be wood,
concrete or ceramic tile.
If floor are covered with
synthetic material, the
relative humidity should
be at least 30%.
Electrical fast
transient/burst
IEC/EN 61000-4-4
2 kV for power supply
lines
2 kV for power
supply lines
Mains power quality
should be that of a
typical commercial or
hospital environment.
Surge
IEC/EN 61000-4-5
1 kV line to line
2 kV line to ground
1 kV line to line
2 kV line to
ground
Mains power quality
should be that of a
typical commercial or
hospital environment.
Power frequency
(50 Hz/60 Hz)
magnetic field
IEC/EN 61000-4-8
30 A/m
30 A/m
Power frequency
magnetic fields should be
at levels characteristic of
a typical location in a
typical commercial or
hospital environment.
Voltage dips, short
interruptions and
voltage variations
on power supply
input lines
IEC/EN
61000-4-11
0 % U
T;
0.5 cycle
At 0°, 45°, 90°, 135°,
180°, 225°, 270° and
315°
0 % U
T
; 1 cycle
and
70 % U
T
; 25/30 cycles )
Single phase: at 0°
0 % U
T
; 250/300 cycle
0 % U
T;
0.5 cycle
At 0°, 45°, 90°,
135°, 180°, 225°,
270° and 315°
0 % U
T
; 1 cycle
and
70 % U
T
; 25/30
cycles )
Single phase: at 0°
0 % U
T
; 250/300
cycle
Mains power quality
should be that of a
typical commercial or
hospital environment. If
the user of the Patient
Monitor requires
continued operation
during power mains
interruptions, it is
recommended that the
Patient Monitor be
powered from an
uninterruptible power
supply or a battery.
NOTE U
T
is the a.c. mains voltage prior to application of the test level.
