Patient Mon
itor User
Manual
Default Settings
- 190 -
ST Analysis
ADU
PED
NEO
ST Analysis
Off
Alarm Switch
Off
Alarm Level
Medium
Alarm Record
Off
Alarm High Limit
(ST-
X)
0.2
Alarm Low Limit
(ST-
X)
-0.2
X stands for
Ⅰ
,
Ⅱ
,
Ⅲ
, aVR, aVL, aVF, V, V1, V2, V3, V4, V5 or V6.
ARR Analysis
ARR Analysis
On
PVCs Alarm Level
Medium
PVCs Alarm Switch
Off
PVCs Alarm Record
Off
ARR Alarm Settings
Alarm Switch
Alarm Level
Alarm Record
ASYSTOLE
On
High
Off
VFIB/VT
AC
On
High
Off
R ON T
On
Medium
Off
VT > 2
On
Medium
Off
COUPLET
On
Medium
Off
PVC
On
Medium
Off
BIGEMINY
On
Medium
Off
TRIGEMINY
On
Medium
Off
TACHY
On
Medium
Off
BRADY
On
Medium
Off
MISSEDBEATS
On
Medium
Off
IRR
On
Medium
Off
PNC
On
Medium
Off
PNP
On
Medium
Off
VBRADY
On
Medium
Off
VENT
On
Medium
Off
198
200
Table of Contents
Default Chapter
5
Table of Contents
5
Chapter 1 Intended Use and Safety Guidance
10
Intended Use/Indications for Use
10
Safety Guidance
10
Environment
10
Power Source Requirements
10
Grounding the Monitor
10
Equipotential Grounding
11
Condensation
11
Safety Precautions
11
Protecting Personal Information
16
Explanation of Symbols on the Monitor
18
Chapter 2 Installation of Monitor
21
Opening the Package and Checking
21
Connecting the Power Cable
21
Powering on the Monitor
22
Connecting Patient Sensors
22
Checking the Recorder
22
Chapter 3 Introduction
23
General Information
23
Screen Display
26
Button Functions
30
Interfaces
31
Built-In Rechargeable Battery
33
Battery Safety Information
33
Battery Status on the Main Screen
33
Checking Battery Performance
34
Replacing the Battery
34
Recycling the Battery
35
Maintaining the Battery
35
Battery Alarm Information
35
Chapter 4 System Menu
36
Patient Setup
37
Default Setup
38
Mark Event
39
Face Select
40
Time Setup
41
Record Setup
41
Module Setup
43
Tracing Waveforms Selection
43
Monitor Version
43
Alarm Volume
44
Key Volume
44
Drug Calculation
44
Waveform Demonstration
44
Maintenance
45
Data Storing
48
Wireless Network with Router (Optional)
51
Chapter 5 Face Select
53
Selecting Operating Screen
53
Standard Screen
53
Trend Screen
53
Oxycrg Screen
54
Large Font Screen
54
Chapter 6 Alarms
57
Alarm Modes
57
Alarm Level
57
Alarm Setup
59
Alarm Cause
61
Audio Alarm Paused
61
Audio Alarm off
62
Alarm Reset
62
Parameter Alarm
62
When an Alarm Occurs
63
Testing Alarms
63
Chapter 7 Alarm Information
64
Physiological Alarm Information
64
Technical Alarm Information
68
Prompts
75
Adjustable Range of Alarm Limits
76
Chapter 8 Freeze
79
General
79
Entering/Exiting Freeze Status
79
FROZEN Menu
79
Reviewing Frozen Waveform
80
Chapter 9 Recording (Optional)
81
General Information on Recording
81
Recording Type
81
Recording Startup
83
Recorder Operations and Status Messages
84
Recorder Alarm Information
85
Chapter 10 Trend and Event
86
Trend Graph
86
Trend Table
87
NIBP Recall
89
Alarm Event Recall
90
Chapter 11 Drug Calculation and Titration Table (Optional)
92
Drug Calculation
92
Titration Table
94
Chapter 12 Maintenance/Cleaning
96
Inspecting
96
Maintenance Task and Test Schedule
96
Care and Cleaning
97
General Points
97
Cleaning
97
Disinfection
101
Cleaning and Disinfecting Other Accessories
103
Replacement of Fuse
103
Cleaning Battery and Battery Compartment Cover
103
Chapter 13 Monitoring ECG/RESP
104
Overview
104
ECG Safety Information
104
Monitoring Procedure
106
Preparation
106
Placing Electrodes for ECG Monitoring
107
ECG Screen Hot Keys
111
ECG Menu
112
Ecg Setup
112
ST Segment Monitoring (Optional)
116
Arr. Monitoring (Optional)
120
Measuring RESP
124
How to Measure RESP
125
Setting up RESP Measurement
125
Installing Electrode for RESP Measurement
126
Resp Setup
126
Chapter 14 Monitoring Spo
129
Overview
129
Spo Safety Information
129
Monitoring Procedure
130
Measurement Limitations
131
Assessing the Validity of a Spo Reading
132
Spo Alarm Delays
132
Perfusion Index (PI)
133
Spo SETUP
133
Chapter 15 Monitoring NIBP
135
Overview
135
NIBP Safety Information
135
Measurement Limitations
136
Measurement Methods
137
Measurement Procedures
137
Nibp Setup
140
Resetting NIBP
141
Calibrating NIBP
141
Leak Test
141
Chapter 16 Monitoring TEMP
143
TEMP Monitoring
143
Temp Setup
143
Chapter 17 Monitoring IBP (Optional)
145
Introduction
145
IBP Safety Information
145
Monitoring Procedure
146
IBP Menu
147
Chapter 18 Monitoring CO (Optional)
154
General
154
Monitoring Procedure
155
Zeroing the Sensor
156
Sidestream CO Module
156
Mainstream CO 2 Module
159
Co 2 Setup
161
Setting CO 2 Corrections
164
Chapter 19 Accessories
166
Chapter 20 Warranty and Service
173
Warranty
173
Contact Information
173
Appendix I Specifications
174
A1.1 Classification
174
A1.2 Specifications
174
A1.2.1 Physical Specifications
174
A1.2.2 Environment
175
A1.2.3 Function Configuration
176
A1.2.4 Display
176
A1.2.5 Battery
176
A1.2.6 Recorder (Optional)
177
A1.2.7 Recall
177
A1.2.8 Ecg
178
A1.2.9 Resp
181
A1.2.10 Nibp
182
A1.2.11 Spo
183
A1.2.12 Pr
184
A1.2.13 Temp
184
A1.2.14 IBP (Optional)
185
A1.2.15 CO (Optional)
185
A1.2.16 Interfaces
191
Appendix II EMC Information
192
A2.1 Electromagnetic Emissions
192
A2.2 Electromagnetic Immunity
192
A2.3 Electromagnetic Immunity
194
A2.4 Recommended Separation Distances
197
Appendix III Default Settings
198
A3.1 Patient Information Default Settings
198
A3.2 Alarm Default Settings
198
A3.3 ECG Default Settings
198
A3.4 Resp
200
A3.5 Spo
200
A3.6 Pr
200
A3.7 Nibp
201
A3.8 Temp
201
A3.9 Ibp
201
A3.10 Co
202
Appendix IV Abbreviations
203
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the EDAN M8 Series and is the answer not in the manual?
Ask a question
EDAN M8 Series Specifications
General
Brand
EDAN
Model
M8 Series
Category
Measuring Instruments
Language
