EDAN M8 Series User Manual

Patient Monitor User Manual System Menu
- 33 -
In the sub-menu, the user may select the REC WAVE1, REC WAVE2 or REC WAVE3, a
maximum of 3 waveforms can be printed out.
The output waveforms can be selected for the following items:
ECG1,
ECG2,
ECG3
ECG1 waveform, ECG2 waveform and ECG3 waveform.
(There will be 7 ECG waveforms on the screen in Full-Lead display mode). If no
ECG waveform is currently displayed on the screen, this item cannot be picked.
SpO
2
SpO
2
Plethysmogram.
(If no SpO
2
waveform is currently displayed on the screen, this item cannot be
picked. In ECG Full-Lead display mode, this item can be picked, although no
SpO
2
waveform is currently displayed on the screen. )
RESP
RESP waveform.
(If no RESP waveform is currently displayed on the screen, this item cannot be
picked. But in ECG Full-Lead display mode, this item can be picked, although no
RESP waveform is currently displayed on the screen.)
IBP1,
IBP2
IBP1 waveform and IBP2 waveform.
(If no IBP waveform is currently displayed on the screen, this item cannot be
picked. But in ECG Full-Lead display mode, this item can be picked, although no
IBP waveform is currently displayed on the screen.)
CO
2
Display CO
2
module waveform.
(If there is no CO
2
waveform on the screen, we cannot choose it. But in full
screen multi-lead mode, we can choose it though we can not see it.)
OFF
No display for this channel.
 RT REC TIME: represents “real-time recording time”, for which two selections are
available: CONTINUAL and 8S (8 seconds). “CONTINUAL” means once pressing the
“Record” button on the front panel, the recorder will continuously print out the waveform or
parameter until the “Record” button is pressed again.
 TIMING REC TIME: represents “time interval between two times of timing recording”.
10 selections are available: “OFF, 10MIN, 20MIN, 30MIN, 40MIN, 50MIN, 1HOUR,
2HOURS, 3HOURS and 4HOURS”. It means that the system will trigger the recording
operation according to the selected time interval. The recording time is fixed at 8 seconds.
NOTE:
RT REC TIME has the higher priority compared with TIMING REC TIME.
 REC RATE: 25.0 mm/s or 50.0 mm/s.
 CLEAR REC TASK: this item can be used to stop recorder from printing out too many
tasks.
