C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 113 –
Configure Details Configures the archive hold time and fault notification settings 519
Show Shows list of configured maintenance domains 519
Configure MA Configure Maintenance Associations 524
Add Defines a unique CFM service instance, identified by its parent MD,
the MA index, the VLAN assigned to the MA, and the MIP creation
method
524
Configure Details Configures detailed settings, including continuity check status and
interval level, cross-check status, and alarm indication signal
parameters
524
Show Shows list of configured maintenance associations 524
Configure MEP Configures Maintenance End Points 529
Add Configures MEPs at the domain boundary to provide management
access for each maintenance association
529
Show Shows list of configured maintenance end points 529
Configure Remote MEP Configures Remote Maintenance End Points 530
Add Configures a static list of remote MEPs for comparison against
the MEPs learned through continuity check messages
530
Show Shows list of configured remote maintenance end points 530
Transmit Link Trace Sends link trace messages to isolate connectivity faults by
tracing the path through a network to the designated target node
532
Transmit Loopback Sends loopback messages to isolate connectivity faults by
requesting a target node to echo the message back to the source
534
Transmit Delay Measure Sends periodic delay-measure requests to a specified MEP within
a maintenance association
536
Show Information
Show Local MEP Shows the MEPs configured on this device 538
Show Local MEP Details Displays detailed CFM information about a specified local MEP in
the continuity check database
539
Show Local MIP Shows the MIPs on this device discovered by the CFM protocol 541
Show Remote MEP Shows MEPs located on other devices which have been discovered
through continuity check messages, or statically configured in the
MEP database
542
Show Remote MEP Details Displays detailed CFM information about a specified remote MEP in
the continuity check database
543
Show Link Trace Cache Shows information about link trace operations launched from this
device
545
Show Fault Notification Generator Displays configuration settings for the fault notification generator 546
Show Continuity Check Error Displays CFM continuity check errors logged on this device 547
OAM Operation, Administration, and Maintenance 549
Interface Enables OAM on specified port, sets the mode to active or passive,
and enables the reporting of critical events or errored frame
events
549
Counters Displays statistics on OAM PDUs 551
Event Log Displays the log for recorded link events 552
Remote Interface Displays information about attached OAM-enabled devices 553
Table 6: Switch Main Menu (Continued)
Menu Description Page
