C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 112 –
RMON Remote Monitoring 471
Configure Global
Add
Alarm Sets threshold bounds for a monitored variable 472
Event Creates a response event for an alarm 475
Show
Alarm Shows all configured alarms 472
Event Shows all configured events 475
Configure Interface
Add
History Periodically samples statistics on a physical interface 477
Statistics Enables collection of statistics on a physical interface 480
Show
History Shows sampling parameters for each entry in the history group 477
Statistics Shows sampling parameters for each entry in the statistics group 480
Show Details
History Shows sampled data for each entry in the history group 477
Statistics Shows sampled data for each entry in the history group 480
Cluster 482
Configure Global Globally enables clustering for the switch; sets Commander status 483
Configure Member Adds switch Members to the cluster 484
Show Member Shows cluster switch member; managed switch members 486
ERPS Ethernet Ring Protection Switching 487
Configure Global Activates ERPS globally 491
Configure Domain 492
Add Creates an ERPS ring 492
Show Shows list of configured ERPS rings, status, and settings 492
Configure Details Configures ring parameters 492
Configure Operation Blocks a ring port using Forced Switch or Manual Switch
commands
508
CFM Connectivity Fault Management 512
Configure Global Configures global settings, including administrative status, cross-
check start delay, link trace, and SNMP traps
515
Configure Interface Configures administrative status on an interface 519
Configure MD Configure Maintenance Domains 519
Add Defines a portion of the network for which connectivity faults can
be managed, identified by an MD index, maintenance level, and
the MIP creation method
519
Table 6: Switch Main Menu (Continued)
Menu Description Page
