C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 111 –
Port/Trunk Details Displays detailed information about a remote device connected to
this switch
434
Show Device Statistics 442
General Displays statistics for all connected remote devices 442
Port/Trunk Displays statistics for remote devices on a selected port or trunk 442
SNMP Simple Network Management Protocol 444
Configure Global Enables SNMP agent status, and sets related trap functions 446
Configure Engine 447
Set Engine ID Sets the SNMP v3 engine ID on this switch 447
Add Remote Engine Sets the SNMP v3 engine ID for a remote device 448
Show Remote Engine Shows configured engine ID for remote devices 448
Configure View 449
Add View Adds an SNMP v3 view of the OID MIB 449
Show View Shows configured SNMP v3 views 449
Add OID Subtree Specifies a part of the subtree for the selected view 449
Show OID Subtree Shows the subtrees assigned to each view 449
Configure Group 452
Add Adds a group with access policies for assigned users 452
Show Shows configured groups and access policies 452
Configure User
Add Community Configures community strings and access mode 457
Show Community Shows community strings and access mode 457
Add SNMPv3 Local User Configures SNMPv3 users on this switch 458
Show SNMPv3 Local User Shows SNMPv3 users configured on this switch 458
Change SNMPv3 Local User Group Assign a local user to a new group 458
Add SNMPv3 Remote User Configures SNMPv3 users from a remote device 460
Show SNMPv3 Remote User Shows SNMPv3 users set from a remote device 458
Configure Trap 463
Add Configures trap managers to receive messages on key events that
occur this switch
463
Show Shows configured trap managers 463
Configure Notify Filter
Add Creates an SNMP notification log 467
Show Shows the configured notification logs 467
Show Statistics Shows the status of SNMP communications 469
Table 6: Switch Main Menu (Continued)
Menu Description Page
