C
HAPTER
17
| Multicast Filtering
Multicast VLAN Registration for IPv4
– 646 –
â—† IGMP snooping and MVR share a maximum number of 1024 groups.
Any multicast streams received in excess of this limitation will be
flooded to all ports in the associated domain.
PARAMETERS
These parameters are displayed:
Configure Profile
◆ Profile Name – The name of a profile containing one or more MVR
group addresses. (Range: 1-21 characters)
◆ Start IP Address – Starting IP address for an MVR multicast group.
(Range: 224.0.1.0 - 239.255.255.255)
◆ End IP Address – Ending IP address for an MVR multicast group.
(Range: 224.0.1.0 - 239.255.255.255)
Associate Profile
◆ Domain ID – An independent multicast domain. (Range: 1-5)
◆ Profile Name – The name of a profile to be assigned to this domain.
(Range: 1-21 characters)
WEB INTERFACE
To configure an MVR group address profile:
1. Click Multicast, MVR.
2. Select Configure Profile from the Step list.
3. Select Add from the Action list.
4. Enter the name of a group profile to be assigned to one or more
domains, and specify a multicast group that will stream traffic to
participating hosts.
5. Click Apply.
Figure 386: Configuring an MVR Group Address Profile
