HAPTER

| Access Control Lists

MAC ACLs

– 957 –

EXAMPLE

Console(config)#access-list mac jerry

Console(config-mac-acl)#

RELATED COMMANDS

permit, deny (957)

mac access-group (960)

show mac access-list (961)

permit, deny

(MAC ACL)

This command adds a rule to a MAC ACL. The rule filters packets matching

a specified MAC source or destination address (i.e., physical layer address),

or Ethernet protocol type. Use the no form to remove a rule.

SYNTAX

{permit | deny}

{any | host source | source address-bitmask}

{any | host destination | destination address-bitmask}

[vid vid vid-bitmask] [ethertype ethertype [ethertype-bitmask]]

{{ip {any | host source-ip | source-ip network-mask}

{any | host destination-ip | destination-ip network-mask}

{ipv6 {any | host source-ipv6 | source-ipv6/prefix-length}

{any | host destination-ipv6 | destination-ipv6/prefix-length}}

[protocol protocol]

[l4-source-port sport [port-bitmask]]

[l4-destination-port dport [port-bitmask]}]

[time-range time-range-name]

no {permit | deny}

{

any | host source | source address-bitmask}

{any | host destination | destination address-bitmask}

[vid vid vid-bitmask] [ethertype ethertype [ethertype-bitmask]]

{{ip {any | host source-ip | source-ip network-mask}

{any | host destination-ip | destination-ip network-mask}

{ipv6 {any | host source-ipv6 | source-ipv6/prefix-length}

{any | host destination-ipv6 | destination-ipv6/prefix-length}}

[protocol protocol]

[l4-source-port sport [port-bitmask]]

[l4-destination-port dport [port-bitmask]}]

OTE

The default is for Ethernet II packets.

Questions and Answers:

J
Jesse RandallAug 10, 2025
What to do if I cannot connect to Edge-Core ECS3510-28T using Secure Shell?
- K
  Kyle Long DDSAug 10, 2025
  If you're having trouble connecting to your Edge-Core Network Router using Secure Shell (SSH), ensure the SSH server's control parameters are correctly configured on the router, and that your SSH client software is properly configured on your management station. Verify that you've generated both RSA and DSA public keys on the router, exported the key to the SSH client, and enabled the SSH service. Consider trying another SSH client or checking for updates to your current SSH client application. Also, confirm that you've set up an account on the router for each SSH user, including a username, authentication level, and password. If you're using public key authentication, ensure you've imported the client's public key to the router.
J
Justin HendersonAug 20, 2025
How to access the onboard configuration program via a serial port connection on Edge-Core Network Router?
- C
  Corey EricksonAug 20, 2025
  If you cannot access the onboard configuration program of your Edge-Core Network Router via a serial port connection, check that your terminal emulator program is set to VT100 compatible, with 8 data bits, 1 stop bit, no parity, and a baud rate of 115200 bps. Also, make sure you are using the RS-232 null-modem serial cable supplied with the router. If you're using a different cable, ensure it conforms to the pin-out connections provided in the Installation Guide.

Edge-Core ECS3510-28T Specifications

General

Model	ECS3510-28T
Switching Capacity	56 Gbps
Forwarding Rate	41.66 Mpps
MAC Address Table Size	16K
Dimensions (W x D x H)	440 x 260 x 44 mm
Weight	3.5 kg
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Ports	24 x 10/100/1000BASE-T
Layer	Layer 2
VLANs	4K
Power Supply	AC: 100~240V AC, 50-60 Hz
Operating Temperature	0 to 50 °C
Storage Temperature	-40°C to 70°C
Jumbo Frame Support	9KB
