SERVICE
For the purposes of this manual, round up/down to the nearest whole integer.
THERMOCOUPLE WORKSHEET (CONTINUED)
PART FAILURE VERIFICATION
°F 0 1 2 3 4 5 6 7 8 9 °C
60 0.791 0.819 0.848 0.876 0.905 0.933 0.962 0.991 1.019 1.048 16
70 1.076 1.105 1.134 1.162 1.191 1.220 1.249 1.277 1.306 1.335 21
80 1.364 1.392 1.421 1.450 1.479 1.508 1.537 1.566 1.594 1.623 27
90 1.652 1.681 1.710 1.739 1.768 1.797 1.826 1.855 1.884 1.913 32
100 1.942 1.972 2.001 2.030 2.059 2.088 2.117 2.146 2.175 2.205 38
350 9.485 9.515 9.546 9.577 9.608 9.639 9.669 9.700 9.731 9.762 177
360 9.793 9.823 9.854 9.885 9.916 9.947 9.977 10.008 10.039 10.070 182
370 10.101 10.131 10.162 10.193 10.224 10.255 10.285 10.316 10.347 10.378 188
380 10.409 10.440 10.470 10.501 10.532 10.563 10.594 10.625 10.655 10.686 193
390 10.717 10.748 10.779 10.810 10.840 10.871 10.902 10.933 10.964 10.995 199
400 11.025
11.056 11.087 11.118 11.149 11.180 11.211 11.241 11.272 11.303 204
410 11.334 11.365 11.396 11.426 11.457 11.488 11.519 11.550 11.581 11.612 210
420 11.642 11.673 11.704 11.735 11.766 11.797 11.828 11.858 11.889 11.920 216
430 11.951 11.982 12.013 12.044 12.074 12.105 12.136 12.167 12.198 12.229 221
440 12.260 12.290 12.321 12.352 12.383 12.414 12.445 12.476 12.506 12.537 227
450 12.568 12.599 12.630 12.661 12.691 12.722 12.753 12.784 12.815 12.846 232
460 12.877 12.907 12.938 12.969 13.000 13.031 13.062 13.093 13.123 13.154 238
470 13.185 13.216 13.247 13.278 13.308 13.339 13.370 13.401 13.432 13.463 243
480 13.494 13.524 13.555 13.586 13.617 13.648 13.679 13.709 13.740 13.771 249
490 13.802 13.833 13.864 13.894 13.925 13.956 13.987 14.018 14.049 14.079 254
500 14.110 14.141 14.172 14.203 14.233 14.264 14.295 14.326 14.357 14.388 260
510 14.418 14.449 14.480
14.511 14.541 14.573 14.603 14.634 14.665 14.696 266
520 14.727 14.757 14.788 14.819 14.850 14.881 14.911 14.942 14.973 15.004 271
530 15.035 15.065 15.096 15.127 15.158 15.189 15.219 15.250 15.281 15.312 277
540 15.343 15.373 15.404 15.435 15.466 15.496 15.527 15.558 15.589 15.620 282
550 15.650 15.681 15.712 15.743 15.773 15.804 15.835 15.866 15.897 15.927 288
560 15.958 15.989 16.020 16.050 16.081 16.112 16.143 16.173 16.204 16.235 293
570 16.266 16.296 16.327 16.358 16.389 16.419 16.450 16.481 16.512 16.542 299
580 16.573 16.604 16.635 16.665 16.696 16.727 16.758 16.788 16.819 16.850 304
590 16.881 16.911 16.942 16.973 17.003 17.034 17.065 17.096 17.126 17.157 310
600 17.188 17.219 17.249 17.280 17.311 17.341 17.372 17.403 17.434 17.464 316
°F 0 1 2 3 4 5 6 7 8 9 °C
To verify of THERMOCOUPLE OFFSET, enter the FACTORY MENU (reference ACCESSING
THE SERVICE MENU in SERVICE OPERATION), using PIN: 7591, navigate to FACTORY →
TEMP → OFFSET.
TYPE-J THERMOCOUPLE CHART
NOTICE
