SERVICE
1. Disconnect the electrical supply and the exible quick disconnect gas
hose from the oven.
2. Remove the two (2) securing screws either side of the gas inlet pipe as
it enters the rear side of the control cabinet. (Figure 4-2)
FIGURE 4-2
FIGURE 4-3
3. Remove the screws securing the lid to the control cabinet. There are
four (4) screws in total, two (2) located on the front and two (2) on the
back. Remove the lid and set aside with the removed screws. (Figure
4-3)
REMOVING THE GAS TRAIN
FIGURE 4-4
GAS CONVERSION (CONTINUED)
4. Remove the four (4) screws on control cabinet door. The control
cabinet door will now lift and swing on its hinges, located on the right
hand side of the door. (Figure 4-4)
