PART NO. DESCRIPTION PART NO. DESCRIPTION
135001.G2 4pc Power Switch
135108-332.
NAT-REP
0.093 BASO Valve, (3240+NAT)
135003-BK 3A Breaker
135108-53.LP-
CONV
0.053 BASO Valve, (3240+LP), pilot/main
orice(specify)
135004-BK 10A Breaker
135108-53.
LP-REP
0.053 BASO Valve, (3240+LP)
135008 OTP Thermostat
135108-53.
NAT-CONV
0.053 BASO Valve, (1830/2440NAT), pilot/
main orice(specify)
135010 G2 Control, UI
135108-53.
NAT-REP
0.053 BASO Valve, (1830/2440NAT)
135011.1 G2 Control, MC
135108-61.LP-
CONV
0.061 BASO Valve, (1830/2440LP), pilot/main
orice(specify)
135026-50VA 25VAC, 50VA Transformer
135108-61.
LP-REP
0.061 BASO Valve, (1830/2440LP)
135032-A 24VDC Relay 135109-PLUG BASO Valve Plug
135032-D
24VAC Relay (can be used in place of
-A)
135120 WAYNE Induction Blower
135036.1B BASO IPI Module 135123 EDGE Induction Fan Assembly
135049 Optical Detector 135130 120VAC Cooling Fan
135050 Detector Flange 135131 Fan Cord (120/240v)
135051-FR Flame Rod with sense wire 135134 240VAC Cooling Fan (CE)
135052 Detector Cable 135137 Fan Filter Media
135055-18 18” Thermocouple, EDGE-30 135138-A 120V VFD (AC TECH) (US/CA/MX Only)
135055-23 23” Thermocouple, EDGE-40 135140 24VDC Power Supply
135055-32 32” Thermocouple, EDGE-60 135142 230V VFD (Lenze) (CE Only)
135055-37 37” Thermocouple, EDGE-70 135142-120
120V (Lenze/Protech) (US/CA/MX Only)
135058
Standing Pilot Burner, with spark wire
(no FR)
135142-120
/240
120V/240V (Invertek) (All Regions)
135060-PC
5 inch, 0.5 OD / 0.25 ID, Silicon Air
Switch Tube
135145 Air Switch
135063 YU-USB Port 135148
24VDC BLDC Conveyor Motor (Extended
harness)
135082.LP LP Valve Spring (order with valve) 135156 Power Receptacle
135082.NAT NAT Valve Spring (order with valve) 135158 14/3 Power Cord
135104 BASO Straight Flange 135160 3/4HP Main Motor, 3PH (60” & 70” Models)
135105 BASO Angle Flange 135165
1/3HP Main Motor, 1PH/60Hz (30” & 40”
Models)
135107.1 Pilot Orice, 7225, LP 135170 Capacitor, 7.5uF/370V (for 135165)
135107.32 Pilot Orice, 7225, LP 135173 Clamp to Main Motor
135108-332.NAT-CONV
0.093 BASO Valve, (3240+NAT), pilot/
main orice(specify)
135175 1830 Main Fan Blade
