INSTALLATION
FIGURE 2-17
OVEN ASSEMBLY
5. Once the skid is free from the support brackets or delivery cart, at a
steady rate and equal height raise both jacks, controlling the oven
during the lift to prevent any unexpected rotation. (Figure 2-17)
6. When the oven is sufciently elevated, carefully remove the delivery
skid or EDGE delivery cart from underneath the oven and relocate
away from the oven installation area. (Figure 2-18)
FIGURE 2-18
7. Continue raising the oven until the oven can be rotated enough so that
the back castors can touch the ground. (Figure 2-19)
8. Slowly continue to raise the oven, while supporting the oven to avoid
over rotation, until the back castors have cleared the ground and the
oven can be rotated enough that the front castors are touching the
oor (Figure 2-20).
FIGURE 2-19
SPINNING OVEN FROM DELIVERY SKID OR EDGE DELIVERY CART (CONT)
