Edimax IC-3110 - Bottom View

WHAT‟S INSIDE
HARDWARE OVERVIEW
Bottom View
ITEM
DESCRIPTION
1-7
MIC
Allows the camera to pick up audio input.
Audio Out
Connects to an audio lead for audio
output.
LAN
Connects to the Ethernet LAN cable.
This port also provides power when
connected to a PoE switch. (IC-3110P
only)
12V DC
Connects to the 12V power adapter.
WPS/Reset
Press this button to activate WPS mode,
or hold the button down for 10 seconds to
reset the camera to factory default settings.
