11-6 Setup
Key function setting
Y
ou can set the functions for <Print>, <Save>, F-key (F1-F4) and footswitch.
To assign a function to a key:
(1) Click to select the desired key in the Key Function column at the left side of the page.
(2) Click to select a function in Function area. You can see the functions selected at the
right side of the select key.
(3) Click [OK] to complete function setting.
The following introduces an example as setting <F4> as !Save AVI Cine to USB disk":
(1) Select F4 in the !Key Function" list at the left side of the page.
(2) Select !Save AVI Cine to USB disk" in !Function" at the right side of the page.
(3) Click [OK] to complete the setting.
In Function area, the functions of user-defined keys can be divided into five categories:
Output, Print, Advances Features, Measurement and Other. Functions are described as
follows:
Type Function Description
Output
Save Image to hard drive
To save an image to the system in the
system-relevant format.
Save Cine To save a cine file to local hard drive.
Save Image to USB disk
To store single-frame image to USB
flash drive:
Save AVI Cine to USB disk Save AVI Cine to USB disk
Save Full Screen Image to
hard drive
To save a full screen image to the
system in the format of JPG or BMP.
To Next Page
