Eickemeyer MAGIC 6000 User Manual

System Overview 2-9
No. Name Description Function
11 /
Alphanumeric
keys
Same as on PC
12 Arrow / Press to enter or exit the arrow comment status.
13 Menu
Main menu Press to display or hide a mode-specific
parameter menu.
14 Cine Cine Review Press to enter or exit the Cine Review status.
15 /
Direction key To adjust LCD brightness or contrast when
pressing with <Fn> key.
16 TGC / Move to adjust time gain compensation.
17
Focus
Freq./THI
/
Press: to switch between Focus and Freq./THI;
Rotate: to adjust corresponding parameter
18
Depth
Zoom
/
Press: to switch between Depth and Zoom;
Rotate: to adjust corresponding parameter
19 Patient
Animal
Information
Press to open/ exit animal information screen.
20 Body Mark
/
Press to enter or exit the Body Mark status.
21 Probe Probe switch Press to switch Probe and Exam Type
22 Comment
/ Press to enter or exit the character comment
status.
23 End Exam / Press to end an exam.
24 Clear
/ Press to clear the comments or measurement
calipers on the screen.
25 Cursor / Press to show the cursor.
26 Nav.Rot / Multifunction knob
27 Quad
Quad-split
screen
Press to enter Quad mode from non-Quad mode;
Press to switch between windows in Quad mode.
28 Dual
Dual-split
screen
Press to enter Dual mode from non-Dual mode;
Press to switch between windows in Dual mode.
29 M / Press to enter the M mode.
30 B / Press to enter the B mode
31 Measure / Press to enter/ exit Application Measurement
32 Update /
Measurement status: press to switch between the
fixed and active end of the caliper;
Multi-imaging mode: press to change the
currently active window.
33 Caliper / Press to enter/ exit general Measurement
34 Gain/ iTouch /
Rotate: to adjust B or M gain
Press: to enter/ exit iTouch
35 Save 1 / Press to save, user-defined key
36 Save 2 / Press to save, user-defined key
