3. Installation
TEC 2000 Installation & Operation Manual E2K-405-0902
3-6
3.5. Discrete Controlled Inputs
The actuator can be controlled by discrete inputs: two-wire control, three-wire control, four-
wire control, and multi-port valve control. Connect the power for these discrete inputs as
detailed in Table 3-1 for external power source. Table 3-2 details connections for the
internal power source. See Section 3.3, Electrical Connections for general electrical
connection requirements.
Table 3-1 External Power Supply
Table 3-2 Internal Power Supply
Terminal Block Function
9 24Vdc (+)
10 0V common
24Vdc(-)
3.6. Auxiliary Control Module (ACM) – Optional
The ACM is an optional module used to expand the functionality of the TEC 2000 Actuator.
There are several versions of the ACM available: Futronic, Controlinc, and Auxiliary Relay
Module (ARM). The Futronic ACM may be used alone or with the ARM stacked on top. The
Controlinc ACM is used with a Communication Adapter Module (CAM). The ARM may also
be installed alone. Each ACM can be supplied with the TEC 2000 Actuator or provided later
as an upgrade.
Terminal
Block
DefaultFunction Alternate Function Voltage
1 Open Valve Port A 18-150Vdc or 20-250Vac
2 Close Valve Port B 18-150Vdc or 20-250Vac
3 Stop Valve Port C 18-150Vdc or 20-250Vac
4 Common for Control Inputs,
Terminals 1-3
0V Common
5 Open Inhibit Multi-Port Sync 18-150Vdc or 20-250Vac
6 Close Inhibit 18-150Vdc or 20-250Vac
7 ESD 18-150Vdc or 20-250Vac
8 Common for Inhibit and
ESD Inputs, Terminals 5-7
0V Common
