3. Installation
TEC 2000 Installation & Operation Manual E2K-405-0902
3-15
Table 3-5 Connecting Actuator A to Actuator B
Terminal Block Function
39 Data Port A (+)
41 Data Port A (-)
40 Shield
43 Data Port B (+)
44 Data Port B (-)
42 Shield
3.7. Auxiliary Relay Module (ARM) Wiring
The ARM can be used with the Futronic ACM or standalone. Only factory-trained
technicians may install the ARM.
Connect the ARM within the controller in accordance with Table 3-6. See Section 3.3,
Electrical Connections for general electrical connection requirements.
Table 3-6 ARM Wiring Connections
Terminal Block Function Relay Type
39 Relay Output #9 Latching No or NC
40 Common
41 Relay Output #10 Latching No or NC
42 Relay Output #11 Latching No or NC
43 Common
44 Relay Output #12 Latching No or NC
