5. Customizing Actuator Settings
TEC 2000 Installation & Operation Manual E2K-405-0902
5-18
Figure 5-10 Discrete Output Setup
Goto next display
see Figure 5-4
DISCRETE
OUTPUT
SETUP?
RELAY #1
LSO
NO
YES
RELAY #1
N.O.
NO
YES
RELAY #1
CONTINUOUS
NO
YES
BACK NEXT
YES
NO
RELAY #2 LSC RELAY #2 N.O.
NO
YES
RELAY #2
CONTINUOUS
NO
YES
YES
NO
FLASHINGN.C.See Function List
See Function List
N.C. FLASHING
RELAY #3
LSA
NO
YES
See Function List
RELAY #3 N.O. RELAY #3
CONTINUOUS
NO
YES
RELAY #4
LSB
NO
YES
YES
NO
N.C. FLASHING See Function List
RELAY #4
N.O.
NO
YES
N.C.
RELAY #4
CONTINUOUS
RELAY #5
MONITOR
NO
YES
RELAY #5
CONTINUOUS
NO
YES
YES
NO
GENERIC
NO
YES
ARM
INSTALLED?
Configure Relays #9 - #12
by repeating the same
process as #1 through #4
LSA
SELECTED?
NO
YES
LSA POSITION
<25%
YES
1-99% in 1%
increments
NO
LSB
SELECTED?
NO
YES
LSB POSITION
>75%
YES
1-99% in 1%
increments
NO
Goto next display
see Figure 5-4
FLASHING
FLASHING
