3. Installation
TEC 2000 Installation & Operation Manual E2K-405-0902
3-8
Table 3-3 ACM Wiring Connections - Futronic (Analog Control Module)
STC Terminal Terminal Name Function
25 Analog Input #1 (+)
26 Analog Input #1 (-)
4-20mA Position Set point
27 Analog Output #1 (+)
28 Analog Output #1 (-)
4-20mA Position Feedback
29 Analog Output #2 (+)
30 Analog Output #2 (-)
4-20mA Torque Feedback
31 (+) External 24Vdc Analog Output Power
Supply Input
32 Earth Ground Analog Cable Shield
Connection
33 Solid State Output #6
34 Solid State Output Common
VFD Open Control Output
35 Solid State Output #7
36 Battery Enable Jumper
VFD Close Control Output
37 Solid State Output #8
38 Battery Enable Jumper
VFD Speed Control Output
