EIM TEC2000 User Manual

2. Quick Start
TEC 2000 Installation & Operation Manual E2K-405-0902
2-1
2 Quick Start
Quick start provides step-by-step instructions for initializing the TEC 2000 actuator. When these
instructions are complete, the position limits will be set and the actuator will be ready for normal
operation.
NOTE: The actuator has been configured as specified by the customer and no further changes
should be required. If full valve data was not provided when ordered, or if changes are needed, see
Section 5, Customizing Actuator Settings.
XWARNING: Use caution when working on, with, or around valves and actuators. High
pressures, forces, voltages, and flammable media can be present.
XWARNING: Verify voltage rating on nameplate before connecting power.
2.1. Set Position Limits
1. Power actuator. The alarm message “SET LIMITS BEFORE OPERATING” will be
displayed. The alarm icon and the yellow LED will be flashing. Valve position will be
displayed as “EE%.”
2. Proceed as follows to set the limits. See Section 5.6.3, Set Valve Travel Limits for
additional details.
A. Enter the “SETUP” mode.
1. Place the selector knob in the STOP position.
2. Rotate the control knob to YES, then NO, then YES, then NO in rapid succession
and then release. The Setup icon will be displayed on the display module and
“SETUP?” will be displayed on the message center.
3. Rotate the control knob to YES. “SET LIMITS BEFORE OPERATING” will be
displayed on the message center.
4. Rotate the control knob to the LOCAL position. The message “CLOSE VALVE
THEN SELECT STOP” will be displayed.
B. Set close valve travel limit.
CAUTION: It is recommended the valve be positioned using the handwheel
while setting the limits to prevent valve damage.
1. Valve Operation
1a. For Electrical Operation use the control knob to move the valve in the
close direction. Proceed to Step No. 2.
1b. For Manual Operation depress the declutch lever while rotating the
handwheel until the clutch is fully engaged. Release the lever. The clutch
will be retained in the handwheel mode by spring-loaded latches. Verify the
valve is fully closed. Move the valve in the open direction for one handwheel
turn to allow for coasting of the motor.
2. When the desired close position is reached, place the selector knob in the STOP
position. “ACCEPT CLOSE LIMIT?” will be displayed.
3. Rotate the control knob to YES. “SELECT LOCAL AND OPEN VALVE” will be
displayed. The close limit is set.
