5. Customizing Actuator Settings
TEC 2000 Installation & Operation Manual E2K-405-0902
5-17
Table 5-3 Relay Output Function List
Function List
LSO (Open
limit)
LOW MAIN BATTERY OVER TORQUE (Open or
Close)
CLOSE INHIBIT
LSC (Close
limit)
LOCAL VALVE STALL LOCAL ESD
LSA
(Intermediate
limit A)
STOP (SS OFF) VALVE DRIFT (MOVED BY
HANDWHEEL)
ESD ACTIVE
LSB
(Intermediate
limit B)
REMOTE LOST POWER LOST ANALOG
OPENING EFM (Electronics fault
monitor)
MOTOR OVERLOAD ACTUATOR FAIL
CLOSING OPEN TORQUE LOST PHASE GENERIC (Controlled by
Network)
MOVING CLOSE TORQUE OPEN INHIBIT LOW RTC BATTERY
Relays #6 through #8 are Solid State Output relays. These relays are added when an ACM
card is installed. These outputs cannot be individually configured. The motor “starter” type
selected in the factory setup mode determines the control. See Table 5-4.
Table 5-4 Solid State Output Relays Configuration
Relay Default Function Alternate
Function
Configure
N.O./N.C.
Configure
Flashing
SSO#6 VFD Open Control Generic No No
SSO#7
VFD Close Control Generic No No
SSO#8
VFD Speed Control Generic No No
