EIM TEC2000 User Manual

5. Customizing Actuator Settings
TEC 2000 Installation & Operation Manual E2K-405-0902
5-19
Relays #9 through #12 are the auxiliary relays when the Auxiliary Relay Module (ARM) is
installed. To configure these relay outputs, follow Step No.1 through No. 3 listed above. See
Table 5-5.
NOTE: The ARM cannot be added when the Controlinc ACM is installed.
Table 5-5 Relay Outputs #9 through #12 Configuration
Relay Default
Function
Configurable
Function
Configure
N.O./N.C.
Default
Setting
Configure
Flashing
RO#9 Lost Power
See Table 5-3
Relay Output
Function List
Yes N.O. Yes
RO#10 Motor Overload
See Table 5-3
Relay Output
Function List
Yes N.O. Yes
RO#11 Lost Phase
See Table 5-3
Relay Output
Function List
Yes N.O. Yes
RO#12 Over Torque
See Table 5-3
Relay Output
Function List
Yes N.O. Yes
