elco THISION L User Manual

10
Technical data
* For italian market only
TH-L
50
TH-L
65
TH-L
85
TH-L
100
TH-L
120
TH-L
145
TH-L
65L *
Nominal heat output at 80/60ºC max/min
kW 45.7/7.6 60.8/10.1 81.1/13.4 92.9/15.6 111.6/18.7 132.2/23.3 56.4/10.1
Nominal heat output at 75/60ºC max/min
kW 45.8/7.6 60.9/10.1 81.3/13.4 93.1/15.6 111.8/18.7 132.5/23.3 56.5/10.1
Nominal heat output at 40/30ºC max/min
kW 48.0/8.4 63.9/11.1 85.3/14.8 100.0/17.2 120.0/20.6 142.3/25.6 59.3/11.1
Nominal heat input Hi max/min
kW 46.9/7.8 62.4/10.4 83.3/13.8 95.2/16.0 114.3/19.2 135.5/23.9 57.9/10.4
Efficiency at 80/60ºC
% 97.4 97.4 97.4 97.6 97.6 97.6 97.4
Efficiency at 40/30ºC
% 102.4 102.4 102.4 105.0 105.0 105.0 102,4
Annual efficiency (NNG 75/60ºC)
% 106.2
Annual efficiency (NNG 40/30ºC)
% >110
Heat Loss (Pstby)
W 122
Max. condensate flow
l/h 7,9 10,4 13,9 18,8 22,7 26,8 9,7
Gas consumption G20 max/min (10,9 kWh/m
3
)
m³/h 4.3/0.7 5.7/1.0 7.6/1.3 8.7/1.5 10.5/1.8 12.4/2.2 5.3/1.0
Gas consumption G25 max/min (8,34 kWh/m
3
)
m³/h 5.6/0.9 7.5/1.2 10.0/1.7 11.4/1.9 13.7/2.3 16.3/2.9 7.0/1.2
Gas consumption G31 max/min (12,8 kWh/kg)
kg/h -/- -/- -/- -/- -/- -/- -/-
Gas pressure G20
mbar 20
Gas pressure G25
mbar 25
Gas pressure G31
mbar -/- -/- -/- -/- -/- -/- -/-
Maximum gas pressure
mbar 50
Max. temperature flue gas (high limit)
°C 90
Flue gas temperature at 80/60ºC max/min
°C 76/63
Flue gas temperature at 40/30ºC max/min
°C 55/39
Flue gas quantity max/min
m³/h 89/14 119/19 159/25 178/29 213/35 253/44 111/19
CO
2
level G20/G25 max/min
% 8.5/8.5 8.5/8.5 8.5/8.5 8.7/8.5 8.7/8.5 8.7/8.5 8.5/8.5
CO
2
level G31 max/min
% -/- -/- -/- -/- -/- -/- -/-
NO
x
level
mg/kWh 39
CO level max/min
mg/kWh 98/7
Max. permissible flue resistance max/min
Pa 150/15 150/15 150/15 150/15 200/15 200/15 150/15
Water volume
l 4.0 4.0 4.7 6.5 8.0 9.4 4.0
Water pressure max/min
bar 8/1.5
Max. water temperature (High limit thermostat)
°C 100
Maximum temperature setpoint
ºC 90
Nominal water flow at dT=20K
m³/h 1.9 2.6 3.4 4.0 4.8 5.6 2.4
Hydraulic resistance at nominal water flow
kPa 9 16 29 15 22 34 14
Electrical connection
V230
Frequency
Hz 50
Mains connection fuse
A10
IP class with Appliance Type B23(P) **
-IP30
IP class with App. Type C13, C33, C43, C53, C63, C83,
-IPX4D
Power consumption boiler max/min (excl. pump)
W 100/25 100/25 100/25 214/38 214/38 221/43 100/25
Power consumption speed controlled pump (opt)
W7575909013013075
Weight (empty)
kg 60 60 68 80 90 97 60
Sound Power Level (LWA) ***
dB 62 62 66 66 68 67 62
Ionisation current average
μA15151515151515
pH value condensate
- 3.2 3.2 3.2 3.2 3.2 3.2 3.2
CE certification code
- CE-0063CM3576
Water connections
- R1.1/4” R1.1/4” R1.1/4” R1.1/2” R1.1/2” R1.1/2” R1.1/4”
Gas connection
- R3/4” R3/4” R3/4” R1” R1” R1” R3/4”
Flue gas connection (DN)
mm 100 130 100
Air intake connection (for room sealed use) (DN)
mm 100 130 100
Condensate connection
mm 22
** With appliance type B23(P) is mandatory to use the air inlet grille. For more information see pag.20
*** Room sealed
