CHAPTER 6: Specifications
IQ-2000 Series Specifications
TABLE 6.1 PDM-10, PDM-20, PDM-30, PDM-75, and PDM-150B Specifications
Drive Module Type PDM-10
(1Φ)
PDM-20
(1Φ)
PDM-30
(1Φ)
PDM-75
(3Φ)
PDM-150B
(3Φ)
Peak Output
Current/Phase
10 amps 20 amps 30 amps 75 amps 150 amps
Continuous Output
Current/Phase
5 amps 10 amps 15 amps 35 amps 65 amps
Continuous Output
Power
1 kW 2 kW 3 kW 7 kW 15 kW
Electrical Characteristics
Line Voltage Input
(50/60 Hz
)
100-240
VAC
100-240
VAC
100-240
VAC
100-240
VAC
100-240
VAC
Continuous Shunt Power 50 W 50 W 50 W 50 W 180W
Peak Shunt Power 4.5 kW 4.5 kW 4.5 kW 10 kW 19 kW
Continuous Shunt External 2.4 kW 2.4 kW 2.4 kW 4 kW 8 kW
Peak Shunt External 6 kW 6 kW 6 kW 10 kW 19 kW
Physical Characteristics
Weight 15 lb
(5 kg)
15 lb
(5 kg)
15 lb
(5 kg)
21 lb
10 kg
31 lb
14 kg
Operating Temperature 32°–140°F (0°–50°C)
Storage Temperature -40°–176°F (-40°–80°C)
Relative humidity 5% to 95% non-condensing
External Shunt Resistor
P/N 9101-1079
Continuous Shunt Power 200 W
Peak Shunt Power 6000 W
