ElectroCraft IQ 2000 - Motor Identification Codes; Part Numbers of Motor Mating Connector Kits

Component Ordering Information 7-3
IQ 2000/5000 Installation Manual
TABLE 7.5 Motor Identification Codes
FACTORY DESIGNATED SPECIAL OPTIONS
AA = STANDARD FLANGE
AN = NEMA56C FLANGE
OPTIONS
00 = STANDARD
01 = 90 Vdc BRAKE
04 = 24 Vdc BRAKE
OPTICAL ENCODER LINE COUNT*
F = 1000
H = 2000 (STANDARD
)
J = 2500
K = 5000
L =500
M = 3000
N = 1500
MOTOR WINDING K
E
DESIGNATOR
SPECIAL ORDER WINDINGS AVAILABLE
FRAME SIZE
SERIES DESIGNATOR
F = FERRITE MAGNET
H = LOW INERTIA
I = INDUCTION
N = RARE EARTH MAGNET
S = RARE EARTH MAGNET
W = WASH DOWN
* Not all line counts are available on all motors
TABLE 7.6 Part Numbers of Motor Mating Connector Kits
Part Number Description
9101-0325 Motor power connector kit, All 2000 and 3000 motors
MS3106F18-4S connector
9101-0326 Motor power connector kit, All 4000 motors
MS3106F208-4S connector
9101-0327 Motor power connector kit, All 6000 motors
MS3106F24-22S connector
9101-0328 Motor power connector kit, All 8000 motors
MS3106F32-17S connector
9101-0329 Encoder connector kit, H-Series, S-Series and F-Series motors
MS3106F20-29S connector)
9101-0330 Brake connector kit, H-Series, S-Series and F-Series motors
MS3106F12S-3S connector
H
-
4 0 3 0
-
QH00
-
AA
