6-2 Specifications
P/N 0013-1027-005 Rev A
IQ-5000 Series
TABLE 6.2 PDM-25, PDM-50, PDM-100, and PDM-150/150X Specifications
Operator Terminal
TABLE 6.3 Operator Terminal Specifications.
Positioning Drive Module PDM-25 PDM-50 PDM-100 PDM-150 PDM-150X
Peak Output
Current/Phase
25 amps 50 amps 100 amps 150 amps 150 amps
Continuous Output
Current/Phase
20 amps 40 amps 50 amps 65 amps 85 amps
Continuous Output
Power
4 kW 8 kW 10 kW 12 kW 15 kW
Physical Characteristics
Weight 15 lb
(5 kg)
15 lb
(5 kg)
15 lb
(5 kg)
21 lb
10 kg
21 lb
10 kg
Operating Temperature 32°–122°F (0°–50°C)
Storage Temperature -40°–176°F (-40°–80°C)
Relative humidity 5% to 95% non-condensing
External Shunt Resistor
Continuous Shunt Power 200 W
Peak Shunt Power 6000 W
Power Supply Module PSM-50 PSM-125
Line Voltage Input
(
3Φ
50/60 Hz
)
100 to 240
VAC
100 to 240
VAC
Fused Disconnect Class RK5
40 amps
Class RK5
90 amps
Output Bus Voltage 100-340 VDC 100-340 VDC
Continuous Output Current 50 amps 100 amps
Continuous Shunt Dissipation 600 W 1200 W
Peak Shunt Power 20 kW 40 kW
Terminal Block Torque 11.0 lb-in
(1.25 Nm)
24.0 lb-in
(2.75 Nm)
Operator Terminal Characteristics Authority
Input voltage
Standard
Optional
110/240 VAC ±15%,
24 VDC or 24 VAC
P/N 9101-2017
P/N 9101-2064
Input power 25 Watts
Temperature
Operating
Storage
32°-131°F (0°-55°C) ambient
-40°-158°F (-40°-70°C) ambient
IEC 68-2-1, Test Ab
IEC 68-2-2, Test Bb
Vibration 5 - 15.3 Hz, 0.25 inch d.a
15.3-500 Hz, 3g
IEC 68-2-6, Test FC
Shock 40g, 9 msec, ½ sine, 18shocks total IEC 68-2-27, Test Ea
Humidity 5% to 95% non-condensing IEC 68-2-3, Test Ca
Weight 7 lb. (3 kg)
Display Vacuum Fluorescent Display, 4 lines by 20 characters
Characters 0.12" wide by 0.2" high
Front panel seal Water tight
Dust tight
NEMA 4 (IP64)
NEMA 12 (IP66)
Exposed materials Bezel: LEXAN® covered with POLANE® T paint
Gasket: PORON® high density cellular urethane
Keyboard: textured polyester with UV hard coating
