Expansion I/O and Memory
Additional memory and I/O may be added with a Memory and I/O Expansion card or an
I/O Expansion Card (Part numbers are listed in Chapter 7, “Component Ordering Informa-
tion”). The expansion card provides the following additional capabilities:
◆ 32 TTL Inputs (I17 through I48),
◆ 16 TTL Outputs (O9 through O24),
◆ four 12-bit Analog inputs (ADC2 through ADC5)
[only available on Memory and I/O card], and
◆ up to 32 KB of nonvolatile memory to the basic PDM for program storage
[only available on Memory and I/O card].
“Option Card Installation” on page 2-6 describes the installation and mounting of the Expansion
I/O card or a Memory and I/O Expansion card. P1 and P2 are designed to connect to a 24-
channel, Opto-22, Generation 4, I/O mounting rack (or compatible) through a 50-pin ribbon
cable. Table 3.15 defines the relationship between P1 and P2 connections on the IQ and terminals
on the expansion board.
The first eight positions on P1 and P2 are outputs and correspond to module positions 16-23 on
a 24-channel expansion board. The last 16 positions of P1 and P2 are inputs and correspond to
module positions 0-15 on a 24-channel expansion board.
TIP
Firmware Version 2.00 or higher is required to use an Expansion I/O card or a
Memory and I/O Expansion card.
TABLE 3.15 P1 and P2 on IQ and Expansion Board Connections
Expansion
I/O Card
Connector P1
and Pin
IQ
I/O Type and
Number
24-channel
Expansion
Board Module
Position
Expansion
I/O Card
Connector P2
and Pin
IQ
I/O Type and
Number
P1-1 Output 9 23 P2-1 Output 17
P1-3 Output 10 22 P2-3 Output 18
P1-5 Output 11 21 P2-5 Output 19
P1-7 Output 12 20 P2-7 Output 20
P1-9 Output 13 19 P2-9 Output 21
P1-11 Output 14 18 P2-11 Output 22
P1-13 Output 15 17 P2-13 Output 23
P1-15 Output 16 16 P2-15 Output 24
P1-17 Input 17 15 P2-17 Input 33
P1-19 Input 18 14 P2-19 Input 34
P1-23 Input 20 12 P2-23 Input 36
P1-21 Input 19 13 P2-21 Input 35
P1-25 Input 21 11 P2-25 Input 37
P1-27 Input 22 10 P2-27 Input 38
P1-29 Input 23 9 P2-29 Input 39
P1-31 Input 24 8 P2-31 Input 40
P1-33 Input 25 7 P2-33 Input 41
P1-35 Input 26 6 P2-35 Input 42
P1-37 Input 27 5 P2-37 Input 43
P1-39 Input 28 4 P2-39 Input 44
P1-41 Input 29 3 P2-41 Input 45
P1-43 Input 30 2 P2-43 Input 46
P1-45 Input 31 1 P2-45 Input 47
P1-47 Input 32 0 P2-47 Input 48
