Transformer Specifications
Multi-tap isolation transformers are available for line voltage matching. The IQ-2000 (PDM-10,
PDM-20 and PDM-30) modules use a single phase transformer. The IQ-5000 (PDM-25, PDM-50,
PDM-100 and PDM-150) modules have a separate power supply module and use a three phase
transformer.
TABLE 6.4 Single Phase Transformer Specifications
TABLE 6.5 Three Phase Transformer Specifications
Refer to Figure 2.22 on page 2-29 and Figure 2.23 on page 2-30 for transformer outline drawings
and load regulation data.
Specification Value
Rating 3.0 kVA
Input
a
a. Single phase input and output (50/60 Hz)
220/ 230/ 240/ 440/ 460/ 480 VAC RMS
Output
a
115/ 230 VAC RMS
Ambient temperature 32°-122°F (0°-50°C)
Specification Model
TF-03 TF-06 TF-12 TF-18
Rating 3 kVA 6 kVA 12 kVA 18 kVA
Weight 86 lb 135 lb 200 lb 325 lb
31 kg 61 kg 91 kg 148 kg
Input
a
a. Three phase input and output (50/60 Hz)
208/ 230/ 240/ 380/ 460/ 480 VAC RMS
Output
a
115/ 230 VAC RMS
Ambient temperature 32°-122°F (0°-50°C)
