ElectroCraft IQ 2000 - Page 50

2-32 Installation P/N 0013-1027-005 Rev A
FIGURE 2.25 IQ-2000 Transformer Outline Diagram
9.20 MAX.
8.00 MIN.
SECONDARY CONNECTIONS
PRIMARY CONNECTIONS
8-32 THD BOLTS
8-32 THD BOLTS
(4.17 DIA)
(4.17 DIA)
2
2
CONNECTION INSTRUCTIONS
1/4-20 GROUND STUD
(6.35 DIA)
(TRANSFORMER CHASSIS)
8.20 MAX.
CLEARANCE RECOMMENDED
FOR ACCESS TO WIRING
NOTES:
1. DIMENSIONS ARE IN INCHES (mm)
2 RING OR SPADE LUG CONNECTORS (NOT PROVIDED)
ARE REQUIRED FOR WIRING CONNECTIONS TO
TRANSFORMER TERMINAL STRIPS.
(210)
(235)
(200)
9.10 MAX.
.XXX±.005
DECIMALS.XX±.010
FRACTIONS:±1/64"
DO NOT SCALE DRAWING
UNLESS OTHERWISE SPECIFIED
ANGLES ±1ANGLES °
TOLERANCE ON:
FILLETS AND ROUNDS .02 R MAX
BREAK ALL EDGES .02 MAX
DIMENSIONS ARE IN INCHES
9101-1056
RELIANCE MOTION CONTROL
Confidential Information of
Eden Prairie, MN 55344
DATE DATE
1-10-89
C
PART NO.
DWG SIZE SHEETSCALE
1:1
11
of
REV ECO CHKRDATEREVISION DESCRIPTION
DIAGRAM,OUTLINE,TRANSFORMER
BY
DESIGN ENGRDRAWN BY
BBBC
2-22-89
17320 2-23-89
A
BC JH
A00759
TM
__
__
B1 CHG’D TEXT
19866
SJ
12-20-91
BC
B
UPDATED TITLE BLOCK
RELEASED
(230)
3.32 ±0.06
(84 ±1.5)
8.00 ±0.06
(203 ±1.5)
MOUNTING HOLES: 0.28 ±0.02 DIA (4)
(7.1 ±0.5)
3kVA TRANSFORMER
ELECTRO-CRAFT P/N 0020-5097
