Analyzer Hardware Overviews | Page 23 of 264
Operating LED
The Operating LED indicates if the unit is presently performing a task directed by the user, for example when
the user has initiated a recording action.
Off:
Unit is not in use and available.
Constant green:
Unit is in use.
Orange:
In use, waiting for event.
Red:
Memory full, downloading.
Trigger LED
The Trigger LED indicates whether a trigger event has occurred. Currently not implemented.
Off:
No trigger event detected.
Green flash:
Trigger event detected.
Capture BR/EDR LED
The Capture BR/EDR LED indicates that the analyzer detects the presence of BR/EDR traffic, irrespective of
whether a recording is underway.
Off:
No BR/EDR traffic detected.
Flashing green:
BR/EDR traffic detected.
