Powering and Controlling the Unit
The Tracker is powered and controlled by the Control Computer over a micro-USB connection, located on the
side opposite the antenna. The unit will generally require just this connection from the Control Computer, but
in cases where the power provided over this connection is insufficient, the Ellisys application software will advise
the user to attach an additional (supplied) cable from any Standard-A USB port on the Control Computer to the
DC Jack in order to deliver the additional power required for the unit to operate.
Figure 8 Tracker Control Port and DC Jack
To prevent damage to your Bluetooth Tracker, use only the cable(s) provided
by Ellisys. Contact Ellisys for replacement details.
