PARAMETER DEFINITION
Timestamp Indicates the timestamps of the last averaging intervals
Flag
Indicates w hether o r n ot t he la st in terval i s v alid
according to the set standard
MEASUREMENT TYPE
Harmonics
Real t ime ( 10/1
2 cycles) cal culation o f s ub g roup
harmonics, in accordance with IEC61000-4-7:
Interharmonics
Real t ime ( 10/12 cy cles) cal culation o f in ter s ub g roup
harmonics, in accordance with IEC61000-4-7
150/180 Cycles
Harmonic
150/180 Cycle averaging of the sub group harmonics
MEASUREMENT TYPE
150/180 Cycles
Interharmonic
150/180 Cycle averaging of the inter sub group harmonics
10 Min Harmonic
10 Minutes averaging of the sub group harmonics
10 Min
Interharmonic
10 Minutes averaging of the inter sub group harmonics
2 Hour Harmonic
2 Hours averaging of the 10 minutes averaging of the sub
group harmonics
2 Hour
Interharmonic
2 Hours averaging of the 10 minutes averaging of the inter
sub group harmonics
Harmonic's
Angle
The angle of each harmonic based on the real time value
