Optional Installations & Disconnections
Attach The PT100 Temperature Connection
The DSP Module of the G4K is equipped with an external connection terminal for a
PT100 T emperature S ensor. T he B LACKBOX is al so eq uipped w ith t wo internal
temperature sensors, one in the DSP module and the second in the PS Module. The
PT100 temperature sensor is an optional device. The temperature module from the
DSP provides reference f or compensation of t emperature r elated reading offsets.
Attachment procedure:
 Remove the PT100 Temperature Sensor provided with the G4K BLACKBOX
unit:
 Connect the sensor to the DSP Module of the G4K:
SEE ALSO
 Connect Power Over Ethernet
 Detach the Voltage Terminal Block Connector
