Nominal
The N ominal s ection d efines t he n ominal A mpere v alues f or al l t he C urrent
Channels from I
1
to I
N
:
Define the Nominal Values (with / ):
If the CT Ratio is inapplicable, then set your values to read:
Primary = Secondary = Nominal
To apply your changes select to review them
NOTE NOTE NOTE ...
For m aximum l ogging r esolution a nd ef ficiency it is r ecommended k eeping
NOMINAL v alues as close t o t he expected normal condition v alues a nd N OT to
maximum values!
SEE ALSO
About Current Window
Current Transformer
Current Polarity
Non-Measured Currents
