G4K Power Quality Analyzer - System Overview
The i nnovative d esign o f the G4 400 BLA CKBOX device se ries i s a t echnological
breakthrough providing the Perfect Permanent PQ Analysis solution. Its enhanced
capabilities are uniquely adaptable to address the individual needs & requirements
for a lmost a ny b usiness and/or ap plication. Empowered by t he patented P QZIP
compression technology, the G4 K can s tore up to a t housand times m ore tha n
other t ypical f ile f ormats. The P QZIP allows the G4 K t o c ontinuously r ecord &
store all electrical waveforms for extended periods with no gaps in the data. Its
superior accuracy yields a 2 x 16 Bit to yield, far surpassing IEC61000-4-30 Class A
requirements. The G4K f eatures a thr eshold-free se tup, & is eq uipped w ith
standard industrial p rotocols f or se amless in tegration i nto a ny SCADA system. I t
provides P Q p arameters acc ording t o E N50160, IEC61000-4-30, & other na tional
standards, and the data may be analyzed over any network at any remote location.
The advanced PQSCADA & Investigator Enterprise Analysis software enables t he
operator to detect, view, control, analyze & isolate the minutest PQ anomaly for
the diagnosis & effective maintenance of equipment. It simplifies troubleshooting
& ti me-synchronized data recorded by an y n umber o f BLACKBOX devices, can b e
compared within a particular site and/or across many sites.
The embedded Website serves as the main user-interface with the unit, providing
enhanced m anagement, unit configuration & r eal-time m onitoring o f all
parameters.
The o ptional G4100 Remote Display LCD Unit (RDU) i s an in tegral p art of t he
Elspec P ower Quality D ata C enter s ystem, al lowing in ter-connectivity w ith th e
G4400 series instruments for configuring and monitoring the electrical distribution
system. The G4 100 c onnects a nd c ommunicates w ith t he G4400 BLA CKBOX
devices d irectly v ia RJ45 n etwork cab le o r t hrough I P c ommunication f rom
anywhere i n the w orld. One R DU c an be us ed to m onitor and c onfigure m any
G4400 series instruments.
