Elspec G4430 - Monitoring Real-Time Data

Monitoring Real-Time Data
The M onitoring se ction d isplays r eal t ime r eadings a nd g raphs o f t he g rid’s
parameters. T he g raph d isplay r equires a n A ctiveX plug-in f rom Gi gasoft th at is
downloadable e ither f rom Elspec's W ebsite's S upport S ection or alt ernatively c an
be installed directly from your BLACKBOX CD. The ActiveX plug-in allows different
view options needed for your PQ Monitoring. In the PQ Monitoring Section you will
be able to monitor the following PQ measurements of your G4K Unit:
 Total measurements in the Summary Window
 Voltage & Current Measurements
 Average Measurements
 Power Measurements
 Internal & External Temperature Readings
 Voltage & Current Phase Diagrams
 Voltage & Current Waveforms
 Short & Long Term Voltage Flickering
 Flickering Waveforms
 Minimum & Maximum Flickering Values
 Voltage & Current Harmonics Spectrum
 Active & Reactive Harmonic Powers
 Voltage & Current Sub & Inter-Harmonics
 Voltage & Current Harmonics in Values & Angles
 Minimum, Maximum Values & Angles of Voltage & Current Harmonics
 Minimum & Maximum Values of Active & Reactive Power Harmonics
